Cooling

Passive

Form factor

microATX

Chipset

AMD [500 Series] A520

Motherboard chipset

AMD A520

Series

Asus TUF Gaming

Number of HDMI outputs

1 st

HDMI version

2.1

HDMI

Yes

Headphone output

Yes

USB

Yes

Number of DisplayPort outputs

1 st

S/PDIF

No

DVI

No

DisplayPort

Yes

DisplayPort version

1.2

USB 2.0

2 st

USB 3.1 Gen 1 (5Gbps)

4 st

Other connectors

VGA

PS/2

1 st

USB 3.2 Gen 2 (10Gbps)

0 st

Type of USB connector

USB (Type A)

USB 3.2 Gen 2x2 (20Gbps)

0 st

Number of SATA ports

4 st

SATA (Serial ATA)

Yes

Internal S/PDIF

1 st

Internal USB 2.0 ports

3 st

Internal USB 3.1 Gen 1 ports (5Gbps)

2 st

Internal USB ports

Yes

M.2

1 st

Internal USB 3.2 Gen 2 ports (10Gbps)

0 st

U.2

0 st

Chassis fan connectors

2 st

Internal USB 3.2 Gen 2x2 ports (20Gbps)

0 st

Max SATA speed

6 Gb/s

Graphics card

No

Support for integrated graphics in CPU

Yes

Width

244 mm

Depth

244 mm

PCIe Express x16

1 st

PCIe Express x1

2 st

PCI slots

0 st

PCIe Express x4

0 st

PCIe Express x8

0 st

PCI Express version

3.0

Security

TPM

Number of Ethernet connections

1 st

Bluetooth version

5.0

Bluetooth

Yes

Wireless network (Wi-Fi)

Yes

Max Ethernet speed

1 Gbit/s

Ethernet connection (RJ45)

Yes

RAID controller

Yes

Support for multiple graphics cards

No

Type of RAID

RAID 0, RAID 1, RAID 10

Sound card

Yes

Sound card chip

Realtek ALC887

Memory slots

4 st

Maximum amount of memory

128 GB

ECC support

Yes

Type of memory

DDR4

Memory speeds

DDR4-3333, DDR4-3200, DDR4-3733, DDR4-2400, DDR4-4000, DDR4-4600, DDR4-2666, DDR4-4466, DDR4-4266, DDR4-2800, DDR4-2133, DDR4-3000, DDR4-4800, DDR4-3600, DDR4-4400, DDR4-3866, DDR4-4133, DDR4-3466

Memory module

DIMM

Maximum RAM frequency

4800

Number of processor sockets

One

Socket

AMD Socket AM4

Integrated CPU

No

64-bit processor

Yes
